Understanding Microstation 95/se: A Basic Guide To Microstation(r), Microstation Modeler(r), And Masterpiece

This easy-to-read guide covers the basics of MicroStation95 (both 2-D CAD drawings and 3-D models) providing readers with concise information and practical applications of this extremely powerful CAD software. Places numerous screen captures alongside discussions to illustrate dialog boxes for tools, settings and options, and provides specific notes that point directly to what is being discussed. Finely focuses discussions, paring down and simplifying the vast amount of information on MicroStation into the basic essentials needed to learn and use the software from a beginning level. Contains numerous examples and exercises which demonstrate software techniques and concepts used in a variety of disciplines, plus poses questions that directly refer to tools, settings, and options covered in the chapter. Considers the advance techniques of the newly released MicroStationSE. For engineers and architects; ideal for use in technical drafting and engineering graphics programs that include CAD.
